Inconel 600 / 601 / 625 / 800 / 825 Pipe
Inconel 600 / 601 / 625 / 800 / 825 Pipe
Inconel 600 / 601 / 625 / 800 / 825 Flanges
Inconel 600 / 601 / 625 / 800 / 825 Forged Fittings
Inconel 600 / 601 / 625 / 800 / 825 Round Bar
Inconel 600 / 601 / 625 / 800 / 825 Plates
Inconel 600 / 601 / 625 / 800 / 825 Fasteners
Inconel 600 / 601 / 625 / 800 / 825 Filler Wire
Inconel 600 Round Bars, Plates, and Fasteners exhibit resistance to corrosion by many organic and inorganic compounds and also makes it virtually immune to chloride-ion stress-corrosion cracking. Inconel 600 Pipes and Pipe Fittings superior tensile toughness, excellent fabricability, and brazeability. Inconel 601 Pipes and Pipe Fittings exhibit high temperature oxidation resistance, remaining highly immune to oxidation through 2200 degrees F, Resists spalling even under severe thermal cycling conditions, Highly immune to carburization, good creep rupture strength, Metallurgical stability, resistance to aqueous corrosion, superior mechanical properties, etc.
Inconel 625 Flanges and Forged Fittings excellent choice for marine applications because of its high corrosion-fatigue strength, superior tensile strength, and immune to chloride-ion stress-corrosion cracking. Inconel 625 Flanges and Forged Fittings can be used in various applications like Chemical process equipment, Flue gas desulfurization scrubbers, Evaporators for wet-process phosphoric acid, etc. Incoloy 800 Round Bars, Plates, and Fasteners are resistant to oxidation and carburization in high temperature environments, exhibit good resistance to corrosion in many acidic environments, outstanding resistance to many sulfur-containing environments, elevated temperature toughness, superior creep rupture strength, etc.
Incoloy 825 Welding Wire exhibit superior reducing and oxidizing acids resistance, good resistance to stress-corrosion cracking, outstanding resistant to localized corrosion, superior resistance to sulfuric and phosphoric acids, good mechanical properties at both room and elevated temperatures up to approximately 1000 degrees F, can be used for pressure vessels at wall temperatures up to degrees F. Inconel 800 Pipes and Pipe Fittings are utilized in wide range of industries like Nuclear power plants, Heat exchangers, Industrial acid and alkali equipment, Vacuum furnace fixtures, Paper mill & alkaline digesters, Vinyl chloride monomer production, Catalyst regenerators in petrochemical production.
At Bhansali Nickel Alloys our objective is to provide only excellent quality of the Inconel 600 Welding Electrode that are suitable for applications in numerous industries. Hence, we conduct various detailed testing on our Inconel 600 Pipes and Pipe Fittings before final delivery. Some of the tests include 100% radiography, raw material test, and flattening test, intergranular corrosion test, chemical analysis and PMI testing. We provide certain tests documents with our Round Bars, Plates, and Fasteners that assure the quality of our Inconel 600 Pipes and Pipe Fittings these include Raw Materials Test Certificate, 100% Radiography Test Report, Third Party Inspection Report, Material Traceability Report, Guarantee Letter, etc. We export these to various cities across the South Africa. Some of the regions that we deliver these products to are Durban, Johannesburg, Soweto, Ekurhuleni, etc.
| Specifications | ASTM B167 B517 / ASME SB 167 SB 517 |
|---|---|
| Outer Diameter | 6.00 mm OD up to 250 mm OD, Sizes up to 12” NB |
| Welded Pipe size | 5.0 mm – 1219.2 mm |
| EFW Pipe size | 5.0 mm – 1219.2 mm |
| Pipe Thickness | 0.3mm – 50 mm |
| Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Form | Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| End | Plain End, Beveled End, Treaded Pipe. |
| Type | Seamless / ERW / EFW / Welded |
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Types | Seamless/Welded |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A815 Grade S31803 Pipe Fitting |
| Specification | ASTM B564 / ASME SB564 |
|---|---|
| Size | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Connect Type/ Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Specifications | ASTM B564 & ASME B564 |
|---|---|
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Types | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Standard | ASTM B166, B466, B408, B425 / ASME SB166, B466, B408, B425 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Size | 10 mm To 100 mm Dia in 100 mm TO 6000 mm Length |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc |
| Finish | Bright, Polish & Black |
| Specifications | ASTM B168, B443, B409, B424 / ASME SB168, B443, B409, B424 |
|---|---|
| Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc. |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Standard | DIN, ASTM, BS and all International Standards |
|---|---|
| Bolt / Screw Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Nuts Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Washers Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Machine Screws Size | M1.6 – M12 |
| Self Tapping Screw Size | No.2 – No. 14 |
| Length | 3 mm to 200 mm |
| Types | Nuts, Bolts, Screws, Stud Bolts, Washers |
| Specification | ASTM A276 / ASME SA276 |
|---|---|
| Size | Dia 6mm to 300mm (100mm to 1200mm long) |
| Diameter | 5.5 – 400 mm |
| Length | Max 12000 mm |
| Types | Wire, Coil Wire, Filler wire, Welding wire etc |
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel 600 | N06600 | 2.4816 |
| Inconel 601 | N06601 | 2.4851 |
| Inconel 625 | N06625 | 2.4856 |
| Inconel 800 | N08800 | 1.4876 |
| Inconel 825 | N08801 | 2.4858 |
| Grade | C | Si | Mn | Cr | S | Ni |
|---|---|---|---|---|---|---|
| Inconel 600 | 0.15 max | 0.50 | 1.00 max | 14.00 – 17.00 | – | 72.00 min |
| Inconel 601 | 0.10 max | 0.50 max | 1.00 max | 21.0 – 25.0 | 0.015 max | 58.0 – 63.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 20.0 – 23.0 | 0.015 max | 58.0 min |
| Inconel 800 | 0.10 max | 1.00 max | 1.50 max | 19.00 – 23.00 | 0.015 max | 30.00 – 35.00 |
| Inconel 825 | 0.05 max | 0.5 max | 1.00 max | 19.50 – 23.50 | 0.03 max | 38.00 – 46.00 |
| Grade | Pipe Density | Pipe Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|---|
| Inconel 600 | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 30000 , MPa – 205 | Psi – 75000 , MPa – 515 | 35% |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 30,000 , MPa – 205 | Psi – 80,000 , MPa – 550 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 75,000 , MPa – 517 | Psi – 1,35,000 , MPa – 930 | 42.5 % |
| Inconel 800 | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 30,000 , MPa – 205 | Psi – 75,000 , MPa – 520 | 30 % |
| Inconel 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 32,000 , MPa – 220 | Psi – 80,000 , MPa – 550 | 30 % |
